Can a 3.5 ton mini excavator be equipped with a long reach boom?
In construction sites where work conditions vary widely, more and more users are considering custom long reach booms to improve the working radius and efficiency of their mini excavators. One common question we often hear is: Can a 3.5 ton mini excavator be fitted with a long reach boom? The answer is: Absolutely yes! However, due to the compact size and limited stability of 3.5-ton machines, there are certain restrictions on the boom length.
1. Is It Possible to Install a Long Reach Boom on a 3.5 Ton Mini Excavator?
Yes, it is! Although 3.5 ton mini excavators are smaller in structure and offer less stability compared to medium or large excavators, they can still be equipped with long reach booms. The only limitation lies in the maximum achievable length—it can’t be extended as far as those on 20 or 30-ton machines.
From our experience, the most commonly used long boom length is 8 meters, with a maximum possible length of 9 meters. These lengths are sufficient for most small-scale river cleaning, ditching, municipal work, and trenching operations.
2. Why Is the Boom Length Limited on 3.5 Ton Machines?
Mini excavators are designed for agility and maneuverability. Installing a longer arm shifts the machine's center of gravity forward and increases its front-end weight, which can lead to stability and safety issues if not properly managed.
To ensure safe operation and structural integrity, it’s important to stay within a reasonable length range:
8 meters: Recommended standard length with good balance between reach and machine stability.
9 meters: Maximum custom length for special job requirements. Requires additional balance adjustments.
3. Counterweight Requirements: A Critical Factor in Long Boom Customization
When a long boom is added, the front-end weight of the machine increases significantly. To maintain balance and prevent tipping, extra counterweight must be added to the rear. Here's a basic guideline for counterweight requirements:
Long Boom Length Required Counterweight
8 meters 600 kg
9 meters 800 kg
8 meters 600 kg
9 meters 800 kg
The counterweights are usually installed at the rear of the excavator and can be custom-made based on the model to ensure proper balance during all operations. A properly calculated counterweight is essential to ensure the machine performs safely and efficiently.
4. Typical Applications for 3.5 Ton Mini Excavator Long Booms
Despite their small size, 3.5 ton mini excavators with long booms are extremely versatile and useful in many compact or complex working environments:
Small river and canal cleaning – Extends reach across banks without moving the excavator, improving efficiency.
Trenching and foundation work – Increases working radius for deeper or farther trenches.
Orchard and mountain work – Ideal for digging long irrigation ditches or drainage systems in hilly terrains.
Dam or levee maintenance – Reach across embankments safely without moving into dangerous areas.
Urban municipal maintenance – Perfect for narrow streets, drainage channels, or roadside slope reinforcement.
5. What to Consider When Customizing a Long Boom for a 3.5 Ton Excavator
When customizing a long reach boom, keep the following in mind:
Provide accurate machine brand and model – Different excavators vary in frame design, hydraulic system, and attachment compatibility.
Define working requirements and target boom length – Select the right length for your most common job types; longer is not always better.
Oil cylinder and hose extensions – Longer booms may require extended hydraulic cylinders and additional piping.
Transportation needs – An 8–9 meter boom may require a detachable design for easier road transport.
6. Choose a Reliable Supplier for Safety and Performance
Since long booms for mini excavators are custom-made products, they require careful structural design, quality materials, and skilled welding. Choosing a reliable manufacturer is essential.
Dewanda specializes in long reach boom customization for small and medium excavators, and we provide global customers with full-service solutions:
Precisely matched designs for all major brands and models;
Free design drawings and installation guidance;
Custom-made counterweights and optional accessories;
Simulated installation testing before delivery;
Fast delivery and international shipping support.
7. Long Boom for 3.5 Ton Mini Excavator
To sum up, installing a long boom on a 3.5 ton mini excavator is not only feasible but also highly practical. With a well-designed arm and the right amount of counterweight, your mini excavator can handle a much wider range of tasks, making it a more versatile and efficient machine.
If you’re looking to improve productivity or expand your working capabilities, consider customizing a long reach boom for your 3.5 ton mini excavator. Contact Dewanda today for the best solution, competitive pricing, and professional support!
